18kg constant speed pan-tilt unit,supports Pelco and optional B/S network or remote control models(1)

JSA-EFPTZDU60 Series

≤18kg

Top load/(side load compatible)

Gear drive

0°～355°

-60°～+10°

9°/S

4°/S

±1°

≤80

Pelco_D

9600

1

AC24V*1、RS485*1、RJ45*1、GND*1；Optional other lines can be customized on demand

AC24V*1、DC12V*1、RS485*1、RJ45*1、GND*1；Optional other lines can be customized on demand

Only the -R model integrates a wireless remote control module,and the remote control distance is ≤100m in an unobstructed environment

Only the -N model supports up/down, left/right rotation, preset position setting/deletion/calling operations based on B/S mode

AC24V 50/60HZ；≤80W

-30℃~+60℃

<90%RH

Input voltage range supply ≤4000V, communication and video signal ≤2000V

IP66

191mm×214mm×291mm
